1.Remove outside window cavity strip
2.Remove the door trim
3.Lower the window 220mm approx (#1 in reference picture)
4.Disconnect battery
5.Remove door window glass washer (#2 in reference picture)
6.Release glass from window regulator (#3 in reference picture)
7.Lift out glass.
Installation is the reverse. Don't forget that the window glass washer (No.2) should be retightened to 14nm.
