1.Remove outside window cavity strip

2.Remove the door trim

3.Lower the window 220mm approx (#1 in reference picture)

4.Disconnect battery

5.Remove door window glass washer (#2 in reference picture)

6.Release glass from window regulator (#3 in reference picture)

7.Lift out glass.

Installation is the reverse. Don't forget that the window glass washer (No.2) should be retightened to 14nm.
